Felicity-G12V200AH-200AH/12V Gel Battery Deep Cycle for Storage Energy Home System
Product Specifications
- Model : G12V200AH
- Cells Per Unit : 6
- Voltage Per Unit : 12
- Capacity : to 1.80V per cel @25℃ 200Ah@10hr-rate
- Weight : 60Kg
- Discharge Current : 2000A (5 sec)
- Internal Resistance : 4.0mΩ
- Recommended Maximum Current Limit Charging : 60A
- Operating Temperature Range : Discharge:-20C~60℃, Charge:0℃~50℃, Storage: 20℃~60℃.
- Normal Operating Temperature Range : 25℃±5℃25℃±5℃
- Float Charging Range : 6 to 13.8V DC/unit Average at 25℃
- Equalization and Cycle Range: 14.4to 14.6V DC/unit Average at 25℃
- Self Discharge GEL batteries can be stored for more than 6 months at 25℃.
- Self-discharge ratio less than 3% per month at 25C.
- Please charge batteries before using.
- Dimensions Size : 522 x 219 x 240 mm.
